Dust Seal SCK-75 75×89×7 NBR Material Construction Hydraulic Seals SCK Wiper Seal
무료샘플과 쿠폰을 위해 나와 연락하세요.
왓츠앱:0086 18588475571
위챗: 0086 18588475571
스카이프: sales10@aixton.com
만약 당신이 어떠한 관심도 가지면, 우리가 24 시간 온라인 도움말을 제공합니다.
x| 부품번호 | SCK-75 | 크기 | 75×89×7 |
|---|---|---|---|
| 브랜드 이름 | NFK | 재료 | NBR |
| 신청 | 기계적 유압 실린더 | 샘플 | 공개 창고 상점, 샘플을 제공 할 수 있습니다 (지불 가능) |
| 배달 시간 | 결제 후 재고가 있는 경우 1-2일, 대량 주문의 경우 7-10일 | 관련 제품 | ISI, 순간단위도, 오디, OUY, OSI, HBY, HBTY, 헤테로바이폴러 트랜지스터, DKB, DKBI, DSI, 라인 퍼 인치, LBI, DKI, DWI인 IDI |
| 이점 | 왕복 운동용 방진 씰 | ||
| 강조하다 | Dust Seal SCK-75 hydraulic wiper,NBR material dust wiper seal,75×89×7 construction hydraulic seal |
||
| TYPE | SIZE | Material | |
|---|---|---|---|
| SCK | 18*30*5.8/7.7 | NBR | |
| SCK | 20*32*5.8/7.7 | NBR | |
| SCK | 25*37*5.8/7.7 | NBR | |
| SCK | 30*42*6.8*/8.7 | NBR | |
| SCK | 40*52*6.8/8.7 | NBR | |
| SCK | 50*62*6.8/8.7 | NBR | |
| SCK | 55*69*7.7/10 | NBR | |
| SCK | 60*74*7.7/10 | NBR | |
| SCK | 65*79*7.7/10 | NBR | |
| SCK | 70*84*7.7/10 | NBR | |
| SCK | 75*89*7.7/10 | NBR | |
| SCK | 80*94*7.7/10 | NBR | |
| SCK | 85*99*7.7/10 | NBR | |
| SCK | 90*104*7.7/10 | NBR | |
| SCK | 95*109*7.7/10 | NBR | |
| SCK | 100*114*7.7/10 | NBR | |
| SCK | 45*57*6.8/8.7 | NBR | |
| SCK | 130*146*8.7/12 | NBR | |
| SCK | 140*160*9.7/14 | NBR | |
| SCK | 30*42*5.8/7.7 | NBR | |
| SCK | 28*40*5.8/7.7 | NBR | |
| SCK | 32*44*6.8/8.7 | NBR | |
| SCK | 105*121*8.7/12 | NBR | |
| SCK | 110*126*8.7/12 | NBR | |
| SCK | 115*131*8.7/12 | NBR | |
| SCK | 120*136*8.7/12 | NBR | |
| SCK | 125*141*8.7/12 | NBR | |
| SCK | 160*180*9.7/14 | NBR | |
| SCK | 132*148*8.7/12 | NBR | |
| SCK | 180*200*9.7/14 | NBR |
Dust Seal SCK-75 75×89×7 NBR Material Construction Hydraulic Seals SCK Wiper Seal
1. Appliion Material :
| Parameter items | Specific content |
| Material | High-performance imported polyurethane |
| Medium | Petroleum-based hydraulic oil, emulsion, not suitable for environmentally safe hydraulic oil (bio-oil). |
| Temperature | -30°C ~ +80°C |
| Pressure | ≤32 Mpa, when the pressure is higher than 20MPa, it is recommended to use a retaining ring. |
| Hardness | 93° (SHA) |
Speed (m/s): 0.5-0.8
Trip (mm): Less than 2000
Sliding resistance: Medium
Characteristics: Excellent oil resistance,This is its most outstanding feature. It can effectively resist mineral oil, vegetable oil, animal oil and most petroleum-based lubricants. Long-term contact will not easily cause swelling, deformation or performance degradation. It is one of the preferred materials for oil sealing scenarios.
It has moderate tensile strength and elasticity, as well as good wear resistance. It can maintain structural stability in dynamic sealing (such as cylinder piston movement) and is not prone to rapid wear due to friction
2. Packaging & Delivery
Packaging Details
Packaging because of different sizes and qty
Delivery Time
1-2 Days For Stocks After Payment, 7-10 Days For Large orders
3. Company Introduction
4. LEAL LIST
Oil seal type: SC, SB, TC, TB, VC, VB, DCY , TC4Y , TCV, TCN and TC4, TB4, DC, DB, VR, MG, OKC3
Piston seal : SPGW SPGO SPG SPGA NCF ODI OSI OUIS OHM OKH DAS , OK SELA OUY
Rod Seal : IDI IUH ISI IUIS
U-Seal : UPI UPH USH USI V99F V96H
Buff Seal : HBTS HBY HBTTS
Wiper Seal : DKB DKBI DKBI3 DKBZ DKI , DWI DKH DWIR DSI LBI LBH VAY
Wearing Ring : WR KZT RYT
Rotary Seal : ROI SPN
Back Up Ring : N4W BRT-PTFE BRT-NYLON BRT2 BRT3 BRT-G BRT-P BRN2 BRN3
O Ring : Oring Kit P series G series AS series S series M 1.5 series M 2.0 series M 1.9series M 2.4 series
M 3.0 series M4.0 series
D Ring : DRP , DRI
| MACHINES SEAL REPAIR KIT | |||
| BOOM CYL' SEAL KIT | HYDAULIC PIMP SEAL KIT | SERVO VALVE SEAL KIT | MAIN PIMP SEAL KIT |
| ARM CYL' SEAL KIT | PIOLVE VALVE SEAL KIT | O RING BOX | SOLENOID VALVE SEAL KIT |
| BUCKET CYL' SEAL KIT | CONTROL VALVE SEAL KIT | BREAKER SEAL REPAIR KIT | BREAKER SEAL REPAIR KIT |
| ADJ CYLINDER SEAL KIT | PUMP PLUNGE SEAL KIT | BREAKER SEAL REPAIR KIT | DRILLING RIG SEAL REPAIR KIT |
| CENTER JIONT KIT | GEAR PUMP SEAL KIT | CRANE SEAL REPAIR KIT | CONCRETE TRAILER PUMP SEAL KIT |
| SWING MOTOR SEAL KIT | AV SEAL KIT | GRADER SEAL REPAIR KIT | CRAWLER BULLDOZER SEAL KIT |
| TRAVEL MOTOR SEAL KIT | ROCK BREAKER SEAL KIT | LOADER SEAL REPAIR KIT | AERRIAL LADDER TRUCK SEAL KIT |
| SERVO VALVE SEAL KIT | MAIN PIMP SEAL KIT | ||
5. picture viewing
